VF-UPI94-2100 universal digital control device is used for monitoring and controlling process values in applications with temperature and analog output sensors. Different alarm options are defined for the outputs.
- Universal Process Input
- Selectable mv, V, mA, thermocuple and RTD input
- Automatic cold point compensation in thermocuple inputs
- Automatic line compensation in RTD connections
- Scale setting and point position selection for mV, mA and V inputs
- Different alarm options
- On-off delay time for alarm functions
- Process value offset
- Easy to change and program set values on the front panel
| Dimensions | 48x96 mm |
|---|---|
| Indicator | 2x4 digits, Top Display: 10mm, Bottom Display: 10mm |
| Process Input | Universal Process Input 4 ... 20mA, 0 ... 20mA, 0 ... 60mV, 0 ... 10V Thermocouple (J, K, R, S, T) PT-100 (Line compensated) |
| Accuracy | %0.3 |
| Control Output | 2 Relay Outputs (8A @ 250Vac) |
| Power Supply | 220Vac, 24Vdc, 12Vdc (It should be determined in order.) |
