TCS9-2200 is a two-set two-output speed measuring + counter device. Input polarity can be easily calibrated as NPN / PNP with quantity-pulse input. Input reading speed and output functions can be adjusted by the user with the help of parameters.
Application Areas
- It can be used in applications where the sum of fluid velocity measurement and fluid quantity is measured.
Features
- 6 + 6 digits LED Display (Green or Red), 8mm digit size
- It is sufficient to enter the flow rate and the number of pulses for calibration.
- NPN / PNP selection (Adjustable with a parameter.)
- Fast reading or adjustable protection time for input
- Adjustable protection time for Up / Down, Gate and Reset inputs
- Output-1 (for speed measurement function) different hysteresis value
- Output-1 (for speed measurement function) delay times at different on / off
- Output-2 (for counter function) NO, NC selection
- Output-2 (for counter function) 4 different output functions
- Adjustable pulse duration for Output-2 (for counter function)
- Program entry lock
- Set1 and set2 input lock (can be set in different parameters)
- The ability to easily change the set point and program it on the front panel
| Dimensions | 96x96 mm |
|---|---|
| Indicator | 2x6 digits, Bottom Display: 14mm, Top Display: 14mm |
| Outputs | 2 Relay Outputs (8A @ 250Vac), Flow Rate Alarm Output, Quantity Counter Output |
| Power Supply | 220Vac, 24Vdc, 12Vdc (It must be specified in order.) |
