VF-ELES5 model level switches; are instruments designed for tank and boiler level control. The float moving according to the fluid level on the guide bar is in point level detection. Special designs can be made according to the fluid, mechanical installation and usage differences. VF-ELES5-S; With 1 "threaded connection, it is produced with a maximum of 2 contacts and 2 floats between 50mm and 1000mm. For detailed information, please contact our company .
| Brand | VFA Electronics |
|---|---|
| Pipe Material | AISI 304 Stainless Steel, Opt. 316SS-PP |
| Float Material | AISI 304 Stainless Steel, Opt. 316SS-PP |
| Connection Material | AISI 304 Stainless Steel, Opt. 316SS-PP |
| Mechanical Connection | G1 |
| Electric Terminal | Connector + PG7 Socket (ISO 4400) |
| Operating Temperature | -20°C ... +150 °C ( 302 °F) |
| Maximum Pressure | 30 Bar (435Psi) |
| Immersion Length Range | 50mm-1000mm |
| Maximum Switching Voltage | 180VDC & 130VAC 10W/VA |
| Maximum Current | 1 A |
| Float Diameter | VF-PC-S1 (28x28x9,4mm) |
| Number of Contacts | Max 2 Pieces |
| Minimum Density | 0.7gr / cm³ (+ 20% recommended) |
| Protection Class | IP67 |
